DT-500MC
The DT-500MC waste compactor is designed specifically for use onboard ships and offshore installations. Manufactured in stainless steel, the DT-500MC comes equipped with a wheeled C-500 container for seamless waste logistics. Its modular design allows for easy source segregation in compliance with MARPOL guidelines by adding extra containers for different waste categories.
Product Description
The DT-500MC can be used as a standalone unit or combined with other DT500series products, with the interchangeable C-500 container facilitating versatility. For optimal waste management efficiency, pairing the DT-500MC waste compactor with a DT-575SR shredder offers extreme volume reduction and reduced handling costs.
To enhance waste containment and disposal, we also offer big bags with inner liner, specially designed for C-500 container.
All Delitek Equipment are equipped with powerful drives to ensures quick and effective waste processing.
The design is based on standard components that a ships engineer can easily deal with in the case something needs to be replaced.
Key Benefits
- Stainless steel design for indoor and outdoor placement.
- Compaction directly into big bags for easy deployment of waste.
- Delitek Products are verified for use in marine and offshore industries by DNV.
- Powerful electro/hydraulic drive for high press-force.
- Easy installation and operation (Plug & Play).
- lternative power supply: Pneumatic/hydraulic.
- EX/ATEX version with DNV unit certification available.
Technical Specification
- Material: Stainless steel AISI 304 or AISI 316
- Capacity: 0,5 m3
- Loading opening (W x H)*: 825x182mm/486x350mm
- Compaction force (Max): Compaction force (Max
- Dimensions (W x D x H): 1016mm x 972mm x 2276mm
- Weight (Incl. container): 361 Kg
- Motor voltage: 220V / 380~440V / 480V / 690V, 3Ph, 50~60Hz
- Motor power: <1,8 kW
- Alternative power supply: Pneumatic/Hydraulic
- Noise level: <65dB Max
