DT-190LCS
Product Description
The DT-190LCS is versatile, capable of shredding various waste categories including mixed consumer waste, paper & cardboard, plastic bottles, aluminium cans, and wood. Its modular design allows for easy source segregation according to MARPOL guidelines by adding extra wheelie bins.
Based on the design of our DT-200series product range, this shredder is stripped of all unnecessary materials to offer exceptional value for money without compromising on quality or reliability.
The pre-installed loading hopper can, if needed, easily be de-mounted for temporary purposes in just a few simple steps.
Security Pillar / Locking mechanism are available as supplementary equipment.
All Delitek Equipment are equipped with powerful drives to ensures quick and effective waste processing.
The design is based on standard components that a ships engineer can easily deal with in the case something needs to be replaced.
Key Benefits
- Stainless steel design for indoor and outdoor placement.
- Ideal for indoor installation onboard vessels and retrofit.
- EUR standard 190L wheelie bin for convenient waste logistics.
- Shredding directly into bags for easy and safe deployment of waste.
- Delitek Products are verified for use in marine and offshore industries by DNV.
- Powerful electric motors for high shaft torque.
- Easy installation and operation (Plug & Play).
Technical Specification
- Material: Stainless steel AISI 304 or AISI316L
- Capacity: 190L
- Loading opening (W x H): 593mm x 395mm
- Dimensions (W x D x H): 781mm x 1103mm x 2072mm(2286mm door fully open)
- Weight (Incl. container): 351,5 Kg
- Motor voltage: 380~440V, 3Ph, 50~60Hz
- Motor power: 3 kW
- Shredding surface: 260mm x 290mm
- Shaft torque: Shaft torque
- Noise level: <70dB Max
